Arch Simplicity Chute Baffle Dust Curtain Suppression System

Simplicity Chute Baffle Dust Suppression from load chutes and head box inlets is a significant source of dust emissions, impacting air quality around conveyor systems. The system is also commonly known as a Dust Curtain.

The Simplicity Chute Baffle traps fugitive dust emissions using a three-stage curtain built into the baffle.

The two outer layers consist of wear-resistant urethane strip curtains with grass skirting, providing extra layers between them to fill gaps and prevent dust from escaping.

When combined with an Arch Dust Fogger system, the Simplicity Chute Baffle, also referred to as a Dust Curtain, will effectively eliminate dust when installed correctly at your transfer points.

Features of Arch Simplicity Chute Baffle:

• The Simplicity Chute Baffle is easy to install at any point along the conveyor.
• Low-maintenance design ensures long-lasting performance with minimal upkeep.
• Corrosion-resistant materials offer enhanced durability in harsh environments.
• It effectively stops high-velocity dust at transfer points, improving air quality.
• Standard baffles are 60cm long and made from 1/4 inch thick polyurethane.
• Heavy-duty baffles are 120cm long and made from 3/4 inch thick polyurethane, suitable for demanding applications.
• Baffles are made to order on the width to meet specific requirements.
• 120cm lengths are available for larger openings, offering greater coverage.
• The overlapping design ensures double protection against fugitive dust emissions.
• Constructed from wear-resistant polyurethane for superior longevity.
• It outlasts and outperforms rubber curtains in both lifespan and effectiveness.
• No field fitting or adjustments are required, making installation straightforward.

Please contact us for pricing as the Simplicity Chute Baffle from Arch Environmental Equipment, Inc. is Price on Application due to fluctuations in the value of the US$.

For full details regarding the Simplicity Chute Baffle and all conveyor accessories, please visit the Arch Environmental Equipment, Inc. website.
