The NM85 Mini Stacker Work Positioner is a compact battery-powered lifting aid with an 85kg capacity, ergonomic controls and precise positioning for pharmaceutical, catering, education, warehouse and industrial applications.
Features of the NM85 Mini Stacker Work Positioner:
- Ergonomic aircraft-style handle suits operators of different heights and helps reduce manual handling strain and workplace injury risks.
- Manual push-button operation controls the battery-powered raising and lowering of the platform for easy load positioning.
- Reduced manual lifting helps operators handle and position loads more easily in workplace environments.
- Four swivel castors allow the unit to manoeuvre in any direction, with rear total-lock swivel brake castors providing secure positioning.
- HDPE platform provides a durable standard load surface for everyday material handling tasks.
- Dual-speed raise and lower control provides a soft start and allows accurate positioning of the platform.
- Overload protection and automatic safety stop provide additional operating protection if anything interferes with the platform during downward travel.
- Maintenance-free sealed gel batteries provide reliable battery-powered lifting without routine battery maintenance.
- Battery condition indicator and on/off switch are conveniently mounted on the handle pod for easy operator access.
- Built-in automatic cut-off charger prevents overcharging of the battery.
- Aluminium mast construction allows the use of six mast rollers and incorporates an overlap-style chain cover.
- Manufactured in Europe for industrial material handling applications.
Specifications for the NM85 Mini Stacker Work Positioner:
| Specification | Details |
| Overall Dimensions: |
798 x 600 x 1600mm |
| Capacity: |
85kg |
| Lifting Range: |
125-1440mm |
| Lift Distance: |
1315mm |
| Platform Dimensions (L x W): |
470 x 600mm |
| Platform Material: |
HDPE |
| Lift Speed: |
63mm/s |
| Battery: |
24V sealed gel battery |
| Motor Power: |
0.3kW |
| Unit Weight: |
37kg |
| Front Castors: |
2 x 80mm swivel castors |
| Rear Castors: |
2 x 100mm total-lock swivel brake castors |
| Mast: |
Aluminium mast with 6 mast rollers and overlap-style chain cover |
| Battery Charger: |
Built-in automatic cut-off charger |
| Country of Manufacture: |
Europe |
Availability: Contact the office for current pricing and availability.
Ideal for pharmaceutical, catering, school, warehouse and industrial environments, this mini stacker, work positioner and mobile lifting platform helps raise, lower and position loads while reducing repetitive manual lifting.
