Galvanised Bike Rail / Hand Rail is a durable one-piece steel solution designed for secure bicycle parking, pedestrian guidance, and impact protection in public and commercial environments.
Features of Galvanised Bike Rail / Hand Rail:
| Specification | Details |
|---|---|
| Description: | One piece steel bike rail |
| Material: | Steel pipe 48mm diameter with 3mm wall |
| Width: | 850mm |
| Height Above Ground: | 800mm |
| Below Ground Depth: | 300mm (BG model only) |
| Finish: | Galvanised (HDG) only or Galvanised (HDG) with safety yellow powder coat |
| Weight: | 9.2kgs approx. |
| Installation BG: | Welded concrete starter bars |
| Installation SM: | 150mm dia x 6mm thick surface flange with 8 of 10x50mm masonry anchors supplied |
| Order Code | Description |
|---|---|
| BR1G-BG | Bike rail 850mm x 800mm high - Below-ground Galvanised |
| BR1P-BG | Bike rail 850mm x 800mm high - Below-ground HDG and powder coated yellow |
| BR1G-SM | Bike rail 850mm x 800mm high - Surface mount Galvanised |
| BR1P-SM | Bike rail 850mm x 800mm high - Surface mount HDG and powder coated yellow |

This bike rail is suitable for schools, shopping centres, walkways, and warehouses as a secure bike rack, hand rail, pedestrian chicane, or impact protection barrier.
It supports safe bicycle parking and helps manage pedestrian and traffic flow in public and commercial spaces.
